XMD2920 Series
XMD2920 Series
Rated Voltage:6V~60VDC
Hold Current:0.30A~3.00A
Max. Current:10A~40A
Temperature Range:-40℃ to 85℃
Features
o Broadest range of surface mount devices available in the industry
o Faster time to trip than standard surface mount devices
o Available in lead-free version
Hold Current:0.30A~3.00A
Max. Current:10A~40A
Temperature Range:-40℃ to 85℃
Features
o Broadest range of surface mount devices available in the industry
o Faster time to trip than standard surface mount devices
o Available in lead-free version
分享:
| Part Number | Hold Current | Trip Current | Rated Voltage | Max. Current | Typ. Power | Max Time to Trip | Resistance | ||
|---|---|---|---|---|---|---|---|---|---|
| IH,A | IT,A | VMax,VDC | IMax,A | Pd, W | Current | Time | RMIN | R1MAX | |
| XMD2920-030 | 0.30 | 0.60 | 60 | 100 | 1.5 | 1.5 | 3.0 | 1.000 | 4.800 |
| XMD2920-050 | 0.50 | 1.00 | 60 | 100 | 1.5 | 2.5 | 4.0 | 0.300 | 1.400 |
| XMD2920-075 | 0.75 | 1.50 | 33 | 40 | 1.5 | 8.0 | 0.3 | 0.180 | 1.000 |
| XMD2920-100 | 1.10 | 2.20 | 33 | 40 | 1.5 | 8.0 | 0.5 | 0.090 | 0.410 |
| XMD2920-125 | 1.25 | 2.50 | 33 | 40 | 1.5 | 8.0 | 2.0 | 0.050 | 0.250 |
| XMD2920-150 | 1.50 | 3.00 | 33 | 40 | 1.5 | 8.0 | 2.0 | 0.050 | 0.230 |
| XMD2920-185 | 1.85 | 3.70 | 33 | 40 | 1.5 | 8.0 | 2.5 | 0.040 | 0.150 |
| XMD2920-200 | 2.00 | 4.00 | 16 | 100 | 1.5 | 8.0 | 4.5 | 0.035 | 0.120 |
| XMD2920-250 | 2.50 | 5.00 | 16 | 100 | 1.5 | 8.0 | 16.0 | 0.025 | 0.085 |
| XMD2920-260 | 2.60 | 5.20 | 6 | 100 | 1.5 | 8.0 | 20.0 | 0.020 | 0.075 |
| XMD2920-300 | 3.00 | 5.20 | 6 | 100 | 1.5 | 8.0 | 25.0 | 0.010 | 0.048 |
IH=Hold current-maximum current at which the device will not trip at 23℃ still air.
IT=Trip current-minimum current at which the device will always trip at 23℃ still air.
T trip=Maximum time to trip(s) at assigned current.
IMAX= Maximum fault current device can withstand without damage at rated voltage (V MAX).
VMAX=Maximum voltage device can withstand without damage at its rated current.
PD Typ=Typical power dissipated from device when in tripped state in 23℃ still air environment.
RMIN=Minimum device resistance at 23℃.
R1MAX=Maximum device resistance at 23℃, 1 hour after tripping .
Agency Approval and Environmental Compliance
| Agency | File Number | Regulation |
| UL, C-UL
TÜV |
E346046 R50213231 |
 |
| Part Number | A | B | C | D | E | |||||
|---|---|---|---|---|---|---|---|---|---|---|
| Min | Max | Min | Max | Min | Max | Min | Max | Min | Max | |
| XMD2920-030 | 6.73 | 7.98 | 4.80 | 5.44 | 0.60 | 1.15 | 0.50 | 1.20 | 0.50 | 0.90 |
| XMD2920-050 | 6.73 | 7.98 | 4.80 | 5.44 | 0.60 | 1.15 | 0.50 | 1.20 | 0.50 | 0.90 |
| XMD2920-075 | 6.73 | 7.98 | 4.80 | 5.44 | 0.40 | 1.15 | 0.50 | 1.20 | 0.50 | 0.90 |
| XMD2920-100 | 6.73 | 7.98 | 4.80 | 5.44 | 0.40 | 1.00 | 0.50 | 1.20 | 0.50 | 0.90 |
| XMD2920-125 | 6.73 | 7.98 | 4.80 | 5.44 | 0.40 | 0.90 | 0.50 | 1.20 | 0.50 | 0.90 |
| XMD2920-150 | 6.73 | 7.98 | 4.80 | 5.44 | 0.40 | 0.90 | 0.50 | 1.20 | 0.50 | 0.90 |
| XMD2920-185 | 6.73 | 7.98 | 4.80 | 5.44 | 0.30 | 0.90 | 0.50 | 1.20 | 0.50 | 0.90 |
| XMD2920-200 | 6.73 | 7.98 | 4.80 | 5.44 | 0.30 | 0.90 | 0.50 | 1.20 | 0.50 | 0.90 |
| XMD2920-250 | 6.73 | 7.98 | 4.80 | 5.44 | 0.30 | 0.90 | 0.50 | 1.20 | 0.50 | 0.90 |
| XMD2920-260 | 6.73 | 7.98 | 4.80 | 5.44 | 0.30 | 0.90 | 0.50 | 1.20 | 0.50 | 0.90 |
| XMD2920-300 | 6.73 | 7.98 | 4.80 | 5.44 | 0.40 | 0.90 | 0.50 | 1.20 | 0.50 | 0.90 |
| Temperature | -40℃ | -20℃ | 0℃ | 23℃ | 30℃ | 40℃ | 50℃ | 60℃ | 70℃ | 85℃ |
|---|---|---|---|---|---|---|---|---|---|---|
| Derating % | 158% | 138% | 119% | 100% | 90% | 81% | 72% | 60% | 50% | 36% |
